Engine
|
|
|
 Type
|
Air cooled, 2 cycle, single cylinder
|
|
Displacement
|
90cc
|
|
Power (BHP @ RPM)
|
 7.0 @ 7000
|
|
Torque (Ft-lbs @ RPM)
|
5.2 @ 7000
|
|
Starting System
|
Electric w/key and brake interlock
|
|
Fuel Capacity
|
1.25 gallons
|
|
Oil Capacity
|
1.5 quarts
|
|
Spark Plug
|
NGK BP7HS or Champion L82YC
|
|
Transmission
|
|
|
Type
|
Automatic (C.V.T., V-Belt)
|
|
Type
|
1/2" Pitch . . . NC420
|
|
Tires & Wheels
|
|
|
Front
|
20 x 7 x 8 Low Pressure Knobby, Steel Rim
|
|
Rear
|
18 x 9.5 x 8 Knobby, Low Pressure Knobby, Steel Rim
|
|
Frame
|
|
|
Type - heavy gauge - jig welded
|
1" 11 ga HREW
|
|
Finish
|
Baked Powder Coat Gloss, Black
|
|
Suspension
|
|
|
Front - independent
|
Oil damped, single A-arm (3")
|
|
Rear - semi-independent
|
Oil damped, single swing shock (4")
|
|
Brake
|
|
|
Front (hand operated)
|
Double drum
|
|
Rear (hand operated)
|
Single drum
|
|
Parking - Hand Operated
|
Rear push button
|
|
Performance
|
|
|
Maximum Speed (Approx)
|
15-30 mph
|
|
Fuel Consumption (Approx)
|
20-30 mpg
|
|
Terrain
|
Hills and slopes, grass, dirt, mud, sand
|
|
Special Features
|
|
|
Seat
|
High Density Foam
|
|
Polypropylene Body with full fenders
|
Red
|
|
Engine Stop Switch
|
Left handlebar and tether
|
|
Other
|
Mud guards, foot/toe guards, flag
|
|
Dimensions
|
|
|
Curb Weight
|
284 lbs.
|
|
Maximum Rider Weight
|
200 lbs.
|
|
Gross Vehicle Weight
|
454 lbs.
|
|
Average seat height
|
27.5 "
|
|
Vehicle: Overall
|
Length 60 "
|
|
.
|
Width 35 "
|
|
.
|
Height 36.5 "
|
